| SPECIFICATIONS | |
| Sampling Frequency | 48 kHz |
| |
| AD Conversion | 24 bits + AF method |
| AF method (Adaptive Focus method) This is a proprietary method from Roland & BOSS that vastly improves the signal-to-noise (SN) ratio of the AD and DA converters. |
| |
| DA Conversion | 24 bits |
| |
| Processing | 32-bit floating point |
| |
| Effects | 97 Types |
| |
| Memories | 36 (User) + 36 (Preset) |
| |
| Phrase Loop | 38 sec. (MONO) |
| |
| Tuner Internal Detection | +/-0.1 cent |
| |
| Nominal Input Level | INPUT: -10 dBu |
| RETURN: -10 dBu |
| |
| Maximum Input Level | INPUT: +7 dBu |
| RETURN: +7 dBu |
| |
| Input Impedance | INPUT: 1 M ohm |
| RETURN: 1 M ohm |
| |
| Nominal Output Level | OUTPUT (L/MONO, R): -10 dBu |
| PHONES: -10 dBu |
| SEND: -10 dBu |
| |
| Output Impedance | OUTPUT (L/MONO, R): 1 k ohm |
| PHONES: 44 ohms |
| SEND: 1 k ohm |
| |
| Recommended Load Impedance | OUTPUT (L/MONO, R): 10 k ohms or greater |
| PHONES: 44 ohms or greater |
| SEND: 10 k ohms or greater |
| |
| Controls | BANK DOWN/AMP switch, BANK UP/EQ switch, CTL/REV switch, |
| MEMORY/MANUAL switch, 1/COMP switch, 2/OD/DS switch, |
| 3/MOD switch, 4/DELAY switch, PEDAL FX switch, |
| Gt. AMP/LINE switch, POWER switch, |
| |
| EXIT button, WRITE button, CTL button, EDIT button, |
| |
| PREAMP TYPE knob, GAIN knob, BASS knob, MIDDLE knob, |
| TREBLE knob, LEVEL knob, |
| REVERB knob, |
| COMP/FX1 TYPE knob, SUSTAIN/SENS/-1OCT knob, |
| ATTACK/TONE/-2OCT/DEPTH knob, LEVEL/PEAK/DIRECT knob, |
| OD/DS TYPE knob, DRIVE knob, TONE knob, LEVEL knob, |
| MOD TYPE knob, RATE/KEY knob, DEPTH/HARMONY knob, |
| E.LEVEL/RESONANCE knob, |
| DELAY TYPE knob, TIME knob, FEEDBACK knob, E.LEVEL knob, |
| OUTPUT LEVEL knob, PEDAL FX TYPE knob, |
| |
| PEDAL FX pedal |
| |
| Display | 7 segments, 2 characters (LED) |
| |
| Connectors | INPUT jack, OUTPUT (L/MONO, R) jacks, SEND jack, RETURN jack: 1/4-inch phone type |
| PHONES jack: Stereo miniature phone type |
| USB COMPUTER port: USB Type-C(R) |
| Bluetooth ADAPTOR connector: Dedicated connector |
| DC IN jack |
| |
| Power Supply | Alkaline battery (AA, LR6) x 4 |
| or |
| AC adaptor |
| |
| Current Draw | 190 mA |
| |
| Expected battery life under continuous use | Alkaline battery: Approximately 6.5 hours |
| * This can vary depending on the specifications of the batteries, capacity of the batteries, and the conditions of use. |
| |
| Accessories | STARTUP GUIDE |
| Alkaline battery (AA, LR6) x 4 |
| Leaflet "USING THE UNIT SAFELY" |
| |
| Options (sold separately) | AC adaptor: PSA-S series |
| Bluetooth(R) Audio MIDI Dual Adaptor: BT-DUAL |
| Carry Bag: CB-ME80,CB-BU10 |
| |
| SIZE AND WEIGHT | |
| Width | 443 mm |
| 17-1/2 inches |
| |
| Depth | 220 mm |
| 8-11/16 inches |
| |
| Height | 67 mm |
| 2-11/16 inches |
| |
| Maximum Height | 93 mm |
| 3-11/16 inches |
| |
| Weight(including battery) | 2.9 kg |
| 6 lb 7 oz |
| |
| * 0 dBu = 0.775 Vrms | |
| *The specifications are subject to change without notice. | |
