| CSP-170 | CSP-150 |
Size/Weight |
Dimensions | Width | 1,412 mm (55-85") (Polished finish: 1,418 mm (55-13/16")) | 1,412 mm (55-85") (Polished finish: 1,418 mm (55-13/16")) |
Height | 1,040 mm (40-15/16") (Polished finish: 1,040 mm (40-15/16")) | 1,040 mm (40-15/16") (Polished finish: 1,040 mm (40-15/16")) |
Depth | 465 mm (18-5/16") (Polished finish: 466 mm (18-6/16")) | 465 mm (18-5/16") (Polished finish: 466 mm (18-6/16")) |
Weight | Weight | 67.0 kg (147 lb, 12 oz) (Polished finish: 69.0 kg (152 lb, 2 oz)) | 58.0 kg (127 lb, 14 oz) (Polished finish: 61.0 kg (134 lb, 8 oz)) |
Control Interface |
Keyboard | Number of Keys | 88 | 88 |
Type | NWX (Natural Wood X) keyboard with synthetic ebony and ivory keytops, escapement | GH3X (Graded Hammer 3X) keyboard with synthetic ebony and ivory keytops, escapement |
Touch Sensitivity | Hard2, Hard1, Medium, Soft1, Soft2, Fixed | Hard2, Hard1, Medium, Soft1, Soft2, Fixed |
88-key Linear Graded Hammers | - | - |
Counterweight | No | No |
Pedal | Number of Pedals | 3 | 3 |
Half Pedal | Yes | Yes |
Functions | Sustain, Sostenuto, Soft, Glide, Style Start/Stop, Volume, etc. | Sustain, Sostenuto, Soft, Glide, Style Start/Stop, Volume, etc. |
GP Response Damper Pedal | - | - |
Display | Type | depending on the Smart Device | depending on the Smart Device |
Size | depending on the Smart Device | depending on the Smart Device |
LCD Brightness | - | - |
Touch Screen | depending on the Smart Device | depending on the Smart Device |
Color | depending on the Smart Device | depending on the Smart Device |
Score Display Function | Yes* | Yes* |
Lyrics Display Function | Yes* | Yes* |
Text Viewer Function | Yes* | Yes* |
Language | 26 Languages (English, Japanese, Germany, French, Spanish, etc.) | 26 Languages (English, Japanese, Germany, French, Spanish, etc.) |
Panel | Language | English | English |
Cabinet |
Key Cover | Key Cover Style | Sliding | Sliding |
Music Rest | Yes | Yes |
Music Clips | Yes | Yes |
Voices |
Tone Generation | Piano Sound | Yamaha CFX, Bösendorfer Imperial | Yamaha CFX, Bösendorfer Imperial |
Binaural Sampling | Yes (Yamaha CFX Voice only) | Yes (Yamaha CFX Voice only) |
Key-off Samples | Yes | Yes |
Smooth Release | Yes | Yes |
VRM | Yes | Yes |
Polyphony | Number of Polyphony (Max.) | 256 | 256 |
Preset | Number of Voices | 692 Voices + 29 Drum/SFX Kits | 692 Voices + 29 Drum/SFX Kits |
Featured Voices | 14 VRM Voices, 113 Super Articulation Voices, 27 Natural! Voices, 27 Sweet! Voices, 63 Cool! Voices, 69 Live! Voices, 30 Organ Flutes! Voices | 14 VRM Voices, 113 Super Articulation Voices, 27 Natural! Voices, 27 Sweet! Voices, 63 Cool! Voices, 69 Live! Voices, 30 Organ Flutes! Voices |
Compatibility | (for song playback) XG, GS , GM, GM2 | (for song playback) XG, GS , GM, GM2 |
Effects |
Types | Reverb | 58 Preset | 58 Preset |
Chorus | - | - |
Master Compressor | - | - |
Master EQ | 5 Preset + User | 5 Preset + User |
Part EQ | - | - |
Intelligent Acoustic Control (IAC) | Yes | Yes |
Stereophonic Optimizer | Yes | Yes |
Insertion Effect | - | - |
Variation Effect | - | - |
Vocal Harmony | VH (44 Preset) | VH (44 Preset) |
Functions | Dual/Layers | Yes | Yes |
Split | Yes | Yes |
Accompaniment Styles |
Preset | Number of Preset Styles | 470 | 470 |
Featured Styles | 396 Pro Styles, 34 Session Styles, 4 Free Play Styles, 36 Pianist Styles | 396 Pro Styles, 34 Session Styles, 4 Free Play Styles, 36 Pianist Styles |
Fingering | Chord Detection Area Full, Chord Detection Area Lower | Chord Detection Area Full, Chord Detection Area Lower |
Style Control | INTRO x 1, ENDING x 1, MAIN x 4, FILL IN x 4 | INTRO x 1, ENDING x 1, MAIN x 4, FILL IN x 4 |
Other Features | Music Finder | - | - |
One Touch Setting (OTS) | - | - |
File Format | - | - |
Songs |
Preset | Number of Preset Songs | 403 | 403 |
Recording | Number of Tracks | 16 | 16 |
Data Capacity | depending on the Smart Device | depending on the Smart Device |
Recording Function | Yes | Yes |
Compatible Data Format | Playback | SMF (Format 0 & 1), XF | SMF (Format 0 & 1), XF |
Recording | SMF (Format 0) | SMF (Format 0) |
Functions |
Lesson/Guide | Lesson/Guide | Correct Key, Any Key, Your Tempo* | Correct Key, Any Key, Your Tempo* |
Guide Lamp | Stream Lights (4 steps) | Stream Lights (4 steps) |
Piano Room | Yes | Yes |
USB Audio Recorder | Playback | Supported format by the Smart Device | Supported format by the Smart Device |
Recording | WAV/AAC | WAV/AAC |
USB Audio | Time Stretch | Yes | Yes |
Pitch Shift | Yes | Yes |
Vocal Cancel | Melody Suppressor | Melody Suppressor |
Miscellaneous | Metronome | Yes | Yes |
Tempo Range | 5 – 500, Tap Tempo | 5 – 500, Tap Tempo |
Transpose | -12 – 0 – +12 | -12 – 0 – +12 |
Tuning | 414.8 – 440.0 – 466.8 Hz | 414.8 – 440.0 – 466.8 Hz |
Scale Type | 9 | 9 |
Audio Recorder/Player | Recording Time (max.) | depending on the Smart Device | depending on the Smart Device |
Audio to Score | Yes | Yes |
Registration Memory | Yes | Yes |
Storage and Connectivity |
Storage | Internal Memory | depending on the Smart Device | depending on the Smart Device |
External Drives | depending on the Smart Device | depending on the Smart Device |
Extensive Connection | Headphones | Standard stereo phone jack (x 2) | Standard stereo phone jack (x 2) |
Microphone | Input Volume, Mic/Line In | Input Volume, Mic/Line In |
MIDI | IN/OUT/THRU | IN/OUT/THRU |
AUX IN | Stereo mini | Stereo mini |
AUX OUT | L/L+R, R | L/L+R, R |
AUX Pedal | Yes | Yes |
RGB OUT | - | - |
USB TO DEVICE | USB TO DEVICE, iPad | USB TO DEVICE, iPad |
USB TO HOST | Yes | Yes |
Amplifiers and Speakers |
Amplifiers | (45 W + 45 W) × 2 | 30 W × 2 |
Speakers | (16 cm + 8 cm) ×2 | 16 cm ×2 |
Acoustic Optimizer | Yes | Yes |
Accessories |
Accessories | Owner’s Manual, Warranty*, Online Member Product Registration, Bench*, Power cord, USB Wireless LAN adaptor*, Owner’s Manual of USB wireless LAN adaptor*, USB cable (USB Type A – USB Type B)*, USB conversion cable (USB Type B – USB Micro B / USB Type B – USB Type C)* *May not be included depending on your area. Check with your Yamaha dealer. | Owner’s Manual, Warranty*, Online Member Product Registration, Bench*, Power cord, USB Wireless LAN adaptor*, Owner’s Manual of USB wireless LAN adaptor*, USB cable (USB Type A – USB Type B)*, USB conversion cable (USB Type B – USB Micro B / USB Type B – USB Type C)* *May not be included depending on your area. Check with your Yamaha dealer. |
